Electrical Specifications:
Power Voltage: 1 phase 220V ±15%
Frequency: 50 Hz
Rated Input Current: 39 A
Output Current Adjustment Range: 20-190 A
Output Voltage: 20.8-27.6 V
No-load Voltage: 58/20 (VRD)
Duty Cycle: 20% at 40℃
Power Factor: 0.72
Efficiency: 86%
Safety and Construction:
Insulation Grade: F
Housing Protection Grade: IP21
Weight: 4 kg
Overall Dimensions: Iron shell - 332x123x200 mm
Electrode Specifications:
Compatible Electrode Sizes: Φ1.6, Φ2.0, Φ2.5, Φ3.2, Φ4.0
Welding Current:Φ1.6 mm: 25-40 A
Φ2.0 mm: 40-65 A
Φ2.5 mm: 50-90 A
Φ3.2 mm: 90-130 A
Φ4.0 mm: 140-190 A
Key Features:
High Grade IGBT Technology: Utilizes the latest IGBT technology for efficient and stable performance.
Intelligent Protection: Features over-loading and over-heating protection, ensuring the machine's longevity and user safety.
Anti-Stick Function: Prevents electrode sticking and facilitates easy removal, enhancing the welding experience.
Fan As Needed Function: Reduces noise and prevents dust accumulation inside the machine, maintaining its performance and durability.
Continuous Welding Capability: Capable of non-stop welding with 3.2mm electrodes and suitable for 4.0mm diameter electrodes.
Portability: Extremely compact and light (not more than 4.0Kg), with an adjustable shoulder strap and handle for easy transport.
Suitable for Various Applications: Ideal for home use, maintenance, installation, etc.
Base Units Include:
1 PCS inverter power source, including a 220V input cord
1 PCS Stick electrode holder, 1.8m cable
1 PCS Earth clamp, 1.2m cable
