MAC AFRIC TIG315P Professional AC/DC MMA/TIG Welding Machine
In stock
SKU
EWELDT315
R 19,995.00

MAC AFRIC TIG315P Professional AC/DC MMA/TIG Welding Machine

In stock
SKU
EWELDT315
R 19,995.00
Check Store Availability
MAC AFRIC TIG315P Professional AC/DC MMA/TIG Welding Machine
In stock
SKU
EWELDT315

Find a Store

More Information
Specifications Description

Model EWELDT315
Power voltage 3PH AC380V±15%
Frequency (Hz) 50/60
Rated input current (A) TIG: 17.2, MMA: 15.5
Output current (A) TIG: 12-300, MMA: 15-240
Duty cycle (%) TIG: 20%, MMA: 60%
No-load voltage (V) 62
Rated output voltage (V) TIG: 22, MMA: 29.6
Pulse duty cycle (%) 10-90
Post time (s) 1-10
Pulse frequency (LF) (Hz) 0.5-15
Pulse frequency (MF) (Hz) 15-450
Basic value current (A) 12-300
Arc initiation current (A) 12-300
Remote control Yes
Arc initiation way HF
Power factor 0.93
Efficiency (%) 85
Insulation grade F
Protection grade IP21

Material Type Welding Method Welding Thickness (mm) Welding Current (A)
Carbon steel, Low alloy steel, Stainless steel, Copper, Titanium DC-TIG 0.5-6.0 12-210
Carbon steel, Low alloy steel, Stainless steel, Copper, Titanium AC-TIG 0.5-6.0 12-210
Al-Si alloy, Aluminum-magnesium alloy MMA welding ∅2.5 ---
Al-Si alloy, Aluminum-magnesium alloy MMA welding ∅3.2 ---
Al-Si alloy, Aluminum-magnesium alloy MMA welding ∅4.0 ---
Al-Si alloy, Aluminum-magnesium alloy MMA welding ∅5.0 ---
Light steel structure, Mild steel, Stainless steel, Alloyed steel Flat, Horizontal 55-85 140-210
Light steel structure, Mild steel, Stainless steel, Alloyed steel Flat, Horizontal 90-130 140-210
Light steel structure, Mild steel, Stainless steel, Alloyed steel Vertical, Over-head 50-80 120-170
Package Weight (kg) 42.760000
Package Length (cm) 72.00
Package Width (cm) 46.01
Package Height (cm) 70.00

Advanced Inverter Technology for Superior Welding Performance

  • Versatile Welding Options: Enjoy TIG AC, TIG DC, and MMA (Stick) welding.
  • Easy Arc Striking: Trigger Start DC TIG and automatic hot start boost current for effortless arc striking.
  • Enhanced Efficiency: More energy-efficient than traditional TIG machines.
  • User-Friendly Controls: Select 2T/4T and repeat functions from the front panel and check the digital display for welding current.
  • Remote Control: Foot pedal capability for convenient remote control.
  • Precision and Protection: Adjustable AC frequency focuses the arc, while AC balance reduces tungsten erosion. The system also protects against over-voltage, over-current, and overheating.
